This function block is used to assign a shuttle stereotype to a shuttle.

Function block

mc_br_shstereotypeassign_acp6d

Interface

I/O	Parameter	Data type	Description
IN	Assembly	Reference to Mc6DAssemblyType	The assembly reference establishes the connection between the function block and an assembly.
IN	Execute	BOOL	Execution of the function block begins on a rising edge of this input.
IN	Name	STRING[32]	Input for the name of the shuttle stereotype
OUT	Done	BOOL	Execution successful, function block finished.
OUT	Busy	BOOL	The function block is active and must continue to be called.
OUT	CommandAborted	BOOL	The command was aborted by another command.
OUT	Error	BOOL	Error during execution.
OUT	ErrorID	DINT	Error number

Table: Parameters
